Part 7: API Design for System Design.

Basketly is a grocery-delivery app. It's illustrative: the company, its numbers and its incidents are made up to show how API decisions fail. Its first API took a weekend to write.

None of these were database or cache bugs. Each was an API design decision made in week one: verbs in paths, offset pagination, no idempotency key, no compatibility rules, slow work inside a request.

Part 1 introduced REST, GraphQL and gRPC in a page, and Part 4 tabled the HTTP methods and status codes. This part is about designing the contract: naming things, paging through millions of them, changing the API without breaking old clients, reporting errors, surviving retries and limits, and running work that takes minutes. In an interview you sketch it in the first ten minutes, and it shapes everything you draw next.

01Chapter 1: What an API Contract Is#

1.1 The Simple Definition#

An API is the contract between a system and the code that calls it: which operations exist, what they take and return, how they fail, and what's promised (ordering, idempotency, limits).

The contract outlives the code behind it. You can rewrite the service or split the database and callers never notice, but you can't change what a shipped mobile app sends, and partners' servers and old phones never update on your schedule. The API is the hardest part of a system to change, so design it on purpose.

1.2 Who Calls It, and Where Each Concern Lives#

%% title: One system, three kinds of callers, and where each API concern lives
flowchart TD
  M@{ icon: "sd:phone", label: "Mobile app<br/>old versions live for years" }
  W@{ icon: "sd:browser", label: "Web app" }
  P@{ icon: "sd:server", label: "Partner servers<br/>API keys, webhooks" }
  GW@{ icon: "sd:gateway", label: "API gateway<br/>auth · rate limits · request IDs" }
  OS["Orders service<br/>validation · idempotency · pagination"]:::core
  CS["Catalog service<br/>filters · sort · cursors"]:::core
  PG@{ icon: "tech:postgresql", label: "PostgreSQL<br/>orders, products" }
  R@{ icon: "tech:redis", label: "Redis<br/>idempotency keys, limit counters" }
  Q@{ icon: "sd:queue", label: "Job queue<br/>long-running exports" }
  WH@{ icon: "sd:webhook", label: "Webhook sender<br/>export.completed" }
  M --> GW
  W --> GW
  P --> GW
  GW --> OS
  GW --> CS
  OS --> PG
  CS --> PG
  OS --> R
  OS --> Q
  Q --> WH
  WH -.-> P
  class M,W,P client
  class GW edge
  class PG store
  class R cache
  class Q queue
  class WH external

The gateway owns cross-cutting rules: who you are, how fast you may go, a request ID on every call. The service owns meaning: what a valid order is, what "the same request again" means, what order a list comes in. The contract must suit the slowest caller to change: the mobile app.

02Chapter 2: Resource Modelling and Naming#

2.1 Nouns, Not Verbs#

Basketly's first API was a list of actions (/createOrder, /getOrders, /cancelOrderNow), and every feature added another. Resource-oriented design models the things and applies a few standard operations to each. Google's API Improvement Proposals: "A typical resource-oriented API exposes a large number of resources with a small number of methods on each resource", the standard ones being "Get, List, Create, Update, Delete" (AIP-121).

2.2 Naming Rules That Pay Off#

• Plural collections, alternating with IDs. "Collection identifiers must be plural", and names "alternate between collection identifiers ... and resource IDs", as in publishers/123/books/les-miserables (AIP-122).
• Nest only for real ownership. An address belongs to a user: /users/{id}/addresses. An order relates to a user and a store, so it lives at /orders/{id} and is listed under each parent. Deep paths make clients carry IDs they don't need.
• Opaque string IDs. Callers mustn't parse them, so you can move from auto-increment to another scheme later. A prefix (ord_8f2k…) makes logs readable.
• One casing everywhere, snake_case or camelCase, never both.

2.3 When It Really Is a Verb#

Cancel an order isn't just PATCH {"status": "cancelled"}: it triggers a refund, recalls a rider, notifies the store. Google's custom method keeps it on the resource: "The HTTP URI must use a : character followed by the custom verb", with POST when it has side effects (AIP-136):

POST /v1/orders/ord_8f2k:cancel
{"reason": "ordered_by_mistake"}

POST /v1/orders/{id}/cancel is a common equivalent. Either way, verbs stay rare, explicit and attached to a resource.

03Chapter 3: Methods and Status Codes That Matter#

Part 4 has the full tables (Networking, Chapter 6). These are the decisions they leave open.

3.1 Safe and Idempotent Are Promises#

RFC 9110: a method is safe if "the client does not request, and does not expect, any state change on the origin server" (GET, HEAD, OPTIONS, TRACE), and idempotent if "the intended effect on the server of multiple identical requests with that method is the same as the effect for a single such request" (those plus PUT and DELETE; not POST). Proxies, SDKs and bots act on these promises: a GET /orders/{id}/confirm gets "confirmed" by a link-preview bot. And POST, the one common non-idempotent method, is the one that creates orders and payments (Chapter 8).

3.2 PATCH vs PUT, and Lost Updates#

PUT replaces the whole resource. Google recommends PATCH, because PUT "becomes a backwards-incompatible change to add fields to the resource" (AIP-134): when v2 adds delivery_instructions, an old client that PUTs what it read silently erases it. A field mask says which fields to touch: PATCH /v1/orders/ord_8f2k?update_mask=address.

Two managers edit one product's price from the same version, and one change is lost. Optimistic concurrency fixes it: GET returns ETag: "v17", the update sends If-Match: "v17", and if the product has changed the server answers 412 Precondition Failed (RFC 9110). The client reloads and asks again.

3.3 Choosing a Status Code#

Stripe's published list includes 402 for "The parameters were valid but the request failed" (a declined card) and 424 for "a failure in a dependency external to Stripe" (Stripe API docs). The client's first question about any code is "should I retry?": 4xx means fix the request first (except 408 and 429), 5xx usually means try later. A 500 for a validation error makes good clients retry something that can never succeed.

04Chapter 4: Pagination#

Paginate every collection from day one. Google: "Adding pagination to an existing RPC is a backwards-incompatible change" (AIP-158), because existing clients assume the first response is the whole list.

4.1 Offset Pagination#

The obvious design is GET /v1/users/{id}/orders?page=1600&per_page=20:

SELECT * FROM orders WHERE user_id = $1
ORDER BY created_at DESC
LIMIT 20 OFFSET 31980;

It's easy to build, and clients can jump to page 7. It also has two flaws that grow with the data.

4.2 Why Offset Breaks at Scale, Worked Through#

%% title: Offset pagination on a list that changes between requests
sequenceDiagram
  autonumber
  participant A as App
  participant API as Orders API
  participant DB as Orders table
  A->>API: GET /orders?page=1 (offset 0)
  API->>DB: ORDER BY created_at DESC LIMIT 20 OFFSET 0
  DB-->>API: O1 ... O20
  API-->>A: page 1 ends with O20
  Note over DB: A new order N arrives at the top
  A->>API: GET /orders?page=2 (offset 20)
  API->>DB: LIMIT 20 OFFSET 20
  DB-->>API: positions 21 to 40, now O20 ... O39
  API-->>A: page 2 starts with O20 again
  Note over A: O20 shown twice. A delete would skip one instead

Slack: "the page window becomes unreliable, potentially skipping or returning duplicate results" (Slack Engineering, 2017).

4.3 Cursor (Keyset) Pagination#

Instead of "skip 39,980 rows", say where you stopped, and let the index jump there. This is the seek or keyset method (Use The Index, Luke: "No Offset"):

SELECT * FROM orders
WHERE user_id = $1
  AND (created_at, id) < ($2, $3)     -- the last row the client saw
ORDER BY created_at DESC, id DESC
LIMIT 21;                             -- page_size + 1 tells us if there's more

Every page walks about 21 entries, page 1 or page 2,000, and a new order lands above the cursor where it can't shift the next page. The id tie-breaker is required: without it, two orders with the same created_at can land on both pages or neither. The API hides the SQL behind an opaque token:

import base64, hashlib, hmac, json

SECRET = b"rotate-me"          # signs tokens so clients can't edit them
MAX_PAGE_SIZE = 100

def _fingerprint(user_id, filters):            # a token is only valid for the query that made it
    return hashlib.sha256(json.dumps([user_id, filters], sort_keys=True).encode()).hexdigest()[:16]

def encode_token(last_row, fp):
    raw = json.dumps({"k": [last_row["created_at"], last_row["id"]], "q": fp}).encode()
    sig = hmac.new(SECRET, raw, "sha256").hexdigest()[:16]
    return base64.urlsafe_b64encode(raw).decode() + "." + sig

def decode_token(token, fp):
    body, sig = token.rsplit(".", 1)
    raw = base64.urlsafe_b64decode(body)
    if not hmac.compare_digest(sig, hmac.new(SECRET, raw, "sha256").hexdigest()[:16]):
        raise ValueError("invalid page_token")                          # → 400
    data = json.loads(raw)
    if data["q"] != fp:
        raise ValueError("page_token was issued for a different query")  # → 400
    return data["k"]

def list_orders(db, user_id, filters, page_size=20, page_token=None):
    page_size = max(1, min(page_size or 20, MAX_PAGE_SIZE))   # coerce down, don't reject
    fp = _fingerprint(user_id, filters)
    sql, args = "SELECT id, created_at, total_paise, status FROM orders WHERE user_id = %s", [user_id]
    if filters.get("status"):
        sql += " AND status = %s"; args.append(filters["status"])
    if page_token:
        sql += " AND (created_at, id) < (%s, %s)"; args += decode_token(page_token, fp)
    sql += " ORDER BY created_at DESC, id DESC LIMIT %s"
    rows = db.query(sql, args + [page_size + 1])
    more = len(rows) > page_size
    rows = rows[:page_size]
    return {"orders": rows, "next_page_token": encode_token(rows[-1], fp) if more else ""}

What the published guidelines insist on:

• Opaque tokens. "Page tokens ... must be opaque (but URL-safe) strings, and must not be user-parseable" (AIP-158). Slack Base64-encodes "information on how to retrieve the next set of results" (Slack Engineering, 2017). Opacity lets you change the scheme per endpoint.
• Empty token = end. That "is the only way to communicate 'end-of-collection'" (AIP-158). A short page isn't the end: filters can return fewer rows.
• Cap, don't reject. Google coerces a large page_size "down to the maximum permitted page size" (AIP-158). Stripe's limit is "between 1 and 100", default 10. GitHub's per_page maximum is "100" for most endpoints.
• Same query across pages. "All other parameters ... must match the call that provided the page token" (AIP-158). The fingerprint enforces it.

The shapes vary. Stripe uses object IDs as cursors (starting_after=obj_foo) with has_more. Microsoft's Azure guidelines return {"value": [...], "nextLink": "{opaqueUrl}"} and omit nextLink on the last page. GitHub puts URLs in a Link header (rel="next", rel="last") and says each endpoint uses "the page, before/after, or since query parameters": page numbers where they're cheap, cursors where they aren't.

4.4 The Trade-off#

Default to cursors. Use page numbers only when the product needs "go to page 7" and deep pages are cheap. A total count is optional either way (AIP-158 makes total_size a "may"), and COUNT(*) on a big table is expensive in its own right.

05Chapter 5: Filtering, Sorting and Sizing a List#

5.1 Filtering and Sorting#

The simple style is one parameter per field: ?category=dairy&in_stock=true. Google uses one filter string in a small language ("a AND b", "a < 42") and returns INVALID_ARGUMENT for a malformed one (AIP-160). For sorting, order_by is "a comma separated list of fields" with a " desc" suffix (AIP-132).

Whatever the syntax, three rules keep a list fast:

1. Every filter and sort you expose has an index behind it. An unindexed filter becomes a full scan the first time a partner calls it in a loop. Publish the allowed fields and reject others with a 400.
2. The cursor holds the sort key plus a unique tie-breaker: (price, id) for price order, (rank, id) for popularity.
3. A token from one sort or filter is rejected for another, as the fingerprint does.

GET /v1/stores/st_12/products?category=dairy&in_stock=true&order_by=rank%20desc&page_size=40

200 OK
{
  "products": [ {"id": "prd_a91", "name": "Toned milk 500 ml", "price_paise": 2800, "in_stock": true} ],
  "next_page_token": "eyJrIjogWzk3LCAicHJkX2E5MSJdLCAicSI6ICIzNDAzZDE0ZjM3NzgxYjBmIn0=.b42b9ae5c719db64"
}

Prices are integer paise, not floating-point rupees: a float can't hold ₹0.10 exactly, and changing the type later breaks clients (Chapter 6).

5.2 Sizing a List Endpoint#

06Chapter 6: Versioning and Backward-Compatible Evolution#

6.1 Compatible and Breaking Changes#

Most changes need no new version if you follow the rules. Google's AIP-180 and GitHub's versioning docs list nearly the same ones:

The client's half of the deal: ignore unknown fields and treat unknown enum values as "other" (a tolerant reader). Put it in your SDKs and docs from day one.

6.2 Three Ways to Version#

Stripe's design, as it described it in 2017, is worth knowing. On an account's first request it is "automatically pinned to the most recent version available", and every later call gets that version implicitly unless a Stripe-Version header overrides it. The code builds only the newest response, then version change modules "walk back through time" to the caller's version. Stripe described keeping integrations working through "almost a hundred backwards-incompatible upgrades over the past six years" (Stripe, 2017). The details have moved on since: as of October 2026 Stripe's docs say it has released new versions monthly with no breaking changes since 2024-09-30.acacia, saves breaking changes for a major release twice a year, and its newer SDKs send the version that was current when the SDK was released.

%% title: Date-pinned versions: build the newest response, then transform it back (after Stripe, 2017)
flowchart TD
  REQ["Request<br/>account pinned to 2016-07-06"]:::service
  H["Handler builds the response<br/>in the newest shape"]:::core
  C3["Change module · 2017-05-24<br/>undo: field renamed"]:::service
  C2["Change module · 2017-02-14<br/>undo: field moved into a sub-object"]:::service
  C1["Change module · 2016-10-19<br/>undo: list became paginated"]:::service
  OUT(["Response in the<br/>2016-07-06 shape"]):::ok
  REQ --> H --> C3 --> C2 --> C1 --> OUT

The changes in the boxes are illustrative; the mechanism is Stripe's.

Publish a deprecation window too: GitHub supports the previous version "for at least 24 more months" after a new one ships. Log which clients still call old shapes, so you know whom to contact first. In an interview, "/v1 in the path, additive-only changes within it" is usually enough; what matters is knowing which changes break clients.

07Chapter 7: Error Contracts#

A good error answers four questions: what kind of failure (a stable machine-readable code), what to tell a human, which input caused it, and whether to retry. The status code only roughly answers the last.

RFC 9457, "Problem Details for HTTP APIs" (it "obsoletes RFC 7807"), is the standard shape, served as application/problem+json: type ("a URI reference that identifies the problem type"), title, status, detail (this occurrence) and instance, and problem types "MAY extend" it with their own members. Basketly's version, with code, param, retryable and request_id as our extensions:

HTTP/1.1 422 Unprocessable Content
Content-Type: application/problem+json

{
  "type": "https://api.basketly.example/errors/slot-unavailable",
  "title": "Delivery slot unavailable",
  "status": 422,
  "detail": "The 6-7 pm slot at store st_12 filled up while you were checking out.",
  "code": "slot_unavailable",
  "param": "delivery_slot",
  "retryable": false,
  "request_id": "req_5d1c"
}

The big guidelines agree on the essentials:

• Google returns google.rpc.Status with an ErrorInfo holding a stable reason, a domain and metadata. If a method has always returned that machine-readable ErrorInfo, the message "may change over time". If clients ever saw errors without it, they "may well have had to resort to parsing" the message, so it must stay fixed (AIP-193).
• Microsoft Azure uses {"error": {"code", "message", "target", "details", "innererror"}}, with code repeated in the x-ms-error-code header.
• Stripe gives a type, a code, a param "to display a message near the correct form field", a message and a doc_url (Stripe API docs).

Clients branch on the code; people read the message. Then you can reword messages freely. Also: never leak stack traces or SQL (log them under the request_id), use one shape for every error including the gateway's 429s, and report all validation failures at once rather than one per round trip.

08Chapter 8: Idempotency at the API Layer#

Week 2, Day 2 · Idempotency in Practice builds the mechanism: key store, races, TTLs. The contract says four things:

1. Every non-idempotent POST accepts a client-generated key, one per logical operation, reused on every retry. Stripe's Idempotency-Key header takes up to 255 characters, suggests V4 UUIDs, and keys may be pruned "after they're at least 24 hours old"; GET and DELETE need none, being "idempotent by definition" (Stripe API docs).
2. A repeat returns the original response. Google's request_id: the server "should return the response for the previously successful request, because the client most likely did not receive the previous response" (AIP-155). Microsoft's equivalent is Repeatability-Request-ID.
3. Same key, different body, is an error. Stripe "compares incoming parameters to those of the original request and errors if they're not the same" (idempotency_error). A request that "conflicts with another request that's executing concurrently" saves no result and can be retried (Stripe API docs).
4. The TTL and scope are documented, so clients know how long a retry stays safe.

Why clients must retry blindly: a call can fail before it arrives, "midway while the server is fulfilling the operation", or "succeed, but the connection break before the server can tell its client about it" (Stripe, 2017). The client can't tell which, so the key has to make every retry safe.

09Chapter 9: Rate Limits as Part of the Contract#

Week 1, Day 3 · Rate Limiting at Scale covers the algorithms and distributed counters. The API's job is to tell clients where they stand, so good ones slow down before they're cut off.

RFC 6585 defines 429: "the user has sent too many requests in a given amount of time", and the response "MAY include a Retry-After header". It leaves what to count, and per whom, up to you. GitHub's REST API allows "60 requests per hour" unauthenticated and "5,000 requests per hour" per user, and reports on every response:

x-ratelimit-limit: 5000
x-ratelimit-remaining: 4987
x-ratelimit-used: 13
x-ratelimit-reset: 1761742800
x-ratelimit-resource: core

Over the limit, GitHub returns "a 403 or 429", and when retry-after is present clients "should not retry your request until after that many seconds has elapsed". It also caps concurrency ("No more than 100 concurrent requests"). X-RateLimit-* is a convention, not a standard: the IETF's RateLimit and RateLimit-Policy fields (e.g. RateLimit: "default";r=50;t=30) were still an Internet-Draft (version 11, May 2026) at the time of writing. Whatever you use, send Retry-After with every 429.

The client's half: honour Retry-After, else back off exponentially with jitter. Stripe recommends waiting "proportionally to 2^n" plus random jitter, which "will space out requests across all clients" (Stripe, 2017).

import random, time, uuid
import requests

RETRYABLE = {408, 429, 500, 502, 503, 504}

def says_retry(resp):                        # e.g. 409 "in progress": the error body's `retryable` flag
    try:
        return resp.status_code >= 400 and resp.json().get("retryable") is True
    except ValueError:
        return False

def create_order(session, body, max_attempts=5):
    key = str(uuid.uuid4())                  # one logical order → one key, reused on every retry
    for attempt in range(max_attempts):
        resp = None
        try:
            resp = session.post("https://api.basketly.example/v1/orders", json=body,
                                headers={"Idempotency-Key": key}, timeout=5)
            if resp.status_code not in RETRYABLE and not says_retry(resp):
                return resp                  # success, or an error that retrying won't fix
        except (requests.ConnectionError, requests.Timeout):
            pass                             # did it land? unknown, and the key makes that fine
        wait = resp.headers.get("Retry-After") if resp is not None else None
        time.sleep(float(wait) if wait and wait.isdigit() else random.uniform(0, 2 ** attempt))
    raise RuntimeError(f"order not confirmed; show 'checking…' and look it up with key {key}")

10Chapter 10: Long-Running Operations#

10.1 202 and a Status Resource#

A three-minute export can't run inside a request: gateways, load balancers and mobile networks drop it, and a second tap starts a second export. Make the work a resource:

%% title: A long-running export: accept, poll a status resource, fetch the result
sequenceDiagram
  autonumber
  participant A as App
  participant API as Exports API
  participant Q as Job queue
  participant W as Worker
  A->>API: POST /v1/invoice-exports (Idempotency-Key k1)
  API->>Q: enqueue job op_42
  API-->>A: 202 Accepted · Location /v1/operations/op_42 · Retry-After 5
  W->>Q: take op_42
  A->>API: GET /v1/operations/op_42
  API-->>A: 200 status running, progress 40
  W->>API: mark op_42 succeeded, file stored
  A->>API: GET /v1/operations/op_42
  API-->>A: 200 status succeeded, result.download_url (signed, 15 min)

RFC 9110's 202 means "accepted for processing, but the processing has not been completed", and the representation "ought to describe the request's current status and point to (or embed) a status monitor". Google's slow methods "should return a google.longrunning.Operation", polled with GetOperation, whose metadata carries "progress, partial failures" and whose done flag marks the end (AIP-151). Microsoft's Azure guidelines return 202 with an Operation-Location header, a retry-after while running, and these states:

%% title: The operation resource's lifecycle (status values as in Microsoft's guidelines)
stateDiagram-v2
  direction LR
  [*] --> NotStarted: POST accepted (202)
  NotStarted --> Running: worker picks it up
  Running --> Succeeded: result stored
  Running --> Failed: error recorded
  NotStarted --> Canceled: cancel requested
  Running --> Canceled: cancel requested
  Succeeded --> [*]
  Failed --> [*]
  Canceled --> [*]
  class Succeeded ok
  class Failed bad

Rules of thumb: the POST takes an idempotency key, so a second tap returns the same op_42; terminal states never change; failures use Chapter 7's error shape; operations expire after a documented time; big results are a link to object storage, not a 2 GB body.

10.2 Polling or Webhooks#

Polling works through any firewall but wastes calls on hour-long jobs. For servers, add a webhook: POST export.completed to a registered URL. Signatures, retries and a receiver that's down for a day are covered in Week 2, Day 4 · Webhook Delivery. Keep the status resource anyway, so a receiver that missed a webhook can catch up. Mobile apps get a push notification instead.

11Chapter 11: REST vs gRPC vs GraphQL#

Part 1 described each style and Part 4 compared gRPC with REST as protocols. The design question is which caller each suits.

Published examples:

• Google defines APIs once in protobuf and maps each method to REST with google.api.http annotations such as get: "/v1/{parent=publishers/*}/books" (AIP-132), so one definition serves gRPC and JSON callers.
• Netflix: "At Netflix, we heavily use gRPC for the purpose of backend to backend communication." Because "some response fields can be expensive to compute", callers send a protobuf FieldMask naming the fields they need. The catch Netflix notes: field names now appear in requests, so renaming one breaks callers (Netflix Technology Blog, 2021).
• GitHub added GraphQL in 2016 because "The REST API is responsible for over 60% of the requests made to our database tier", and responses "simultaneously sent too much data and didn't include data that consumers needed" (GitHub, 2016). It then had to price queries: 5,000 points an hour per user, a required first/last of 1–100 on every connection, and at most "500,000 total nodes" per call (GitHub GraphQL docs).
• Shopify: "The REST Admin API is a legacy API as of October 1, 2024. Starting April 1, 2025, all new public apps must be built exclusively with the GraphQL Admin API" (Shopify docs).

GraphQL moves work to the server: the N+1 problem, "commonly solved by a batching technique ... like Facebook's DataLoader", and the need for "limiting operation depth and breadth, and query complexity analysis" before it faces the internet (graphql.org).

%% title: Choosing an API style for one caller
flowchart TD
  S{"Who calls it?"}
  EXT{"External developers<br/>or browsers?"}
  INT{"Your own services,<br/>high volume or streaming?"}
  UI{"Your own UIs with<br/>many different screens?"}
  REST(["REST + JSON<br/>cursors, idempotency keys, versions"]):::ok
  GRPC(["gRPC + Protobuf<br/>deadlines, FieldMask, codegen"]):::ok
  GQL(["GraphQL or a BFF<br/>with cost limits, DataLoader"]):::ok
  S --> EXT
  S --> INT
  S --> UI
  EXT -->|"yes"| REST
  INT -->|"yes"| GRPC
  INT -->|"no, simple CRUD"| REST
  UI -->|"yes, fast-changing"| GQL
  UI -->|"few screens"| REST

Most systems use several: REST at the edge, gRPC inside, and sometimes GraphQL or a backend-for-frontend (BFF) for the apps. In an interview, default to REST for the public API and name the alternative you rejected.

12Chapter 12: Real-Time APIs at a Glance#

Part 4 explains the protocols; Week 6, Day 3 · Real-Time Channels runs them at scale. As API shapes:

Across all four: every event carries an ID and sequence so clients can resume, the stream carries notifications, not the record (the client can always GET the truth), and the stream is authorised like any other resource.

13Chapter 13: Auth Basics for APIs#

• API keys identify a calling application or account: long-lived secrets on every request, server to server. Stripe's types show the range: a publishable key that is "safe to expose" but "can't perform sensitive operations", restricted keys "with permissions you control", and secret keys with "unrestricted permissions", which Stripe now steers new uses away from. "Only publishable keys are safe to expose outside your application's back end."
• OAuth 2.0 access tokens let "a third-party application ... obtain limited access to an HTTP service" on a user's behalf (RFC 6749). They carry scopes, expire, and travel as Authorization: Bearer …. Use them when a user grants an app access ("let this budgeting app read my orders").

The rules: no credentials in URLs (they end up in logs); least privilege per key and token; 401 for bad credentials, 403 (or 404) for no access; and rotation without downtime (Stripe keeps old and new keys working "for up to 7 days"). Week 9, Day 5 · Security Architecture goes deeper.

14Chapter 14: Common Mistakes#

1. Verbs in paths. /getOrdersForUserV2 makes every feature a one-off. Use resources and standard methods, with a rare :verb.
2. Unpaginated or offset-paginated lists. Fine at 50 items, broken at 50,000, and adding pagination later breaks clients. Cursors from day one, page_size capped.
3. Breaking changes inside a version. Add alongside, deprecate, remove only in a new version after a published window.
4. Retry-unsafe POSTs. Without an idempotency key, every timeout on an order or payment can become a duplicate.
5. Slow work inside a request. Anything that can take more than a few seconds becomes 202 and an operation.

15Chapter 15: API Design in the Interview#

15.1 The First 10 Minutes#

Part 1's framework puts API contracts in the deep dive, and the course plan's RADCE order (Requirements → API → Data → Core components → Extended features) puts them right after requirements. Do both: a 4-minute sketch after requirements and estimates, then detail on one endpoint if asked.

POST /v1/orders                       Idempotency-Key · 201 + Location
GET  /v1/orders/{id}                  current state, ETag
GET  /v1/users/me/orders?page_size&page_token     cursor-paginated history
POST /v1/orders/{id}:cancel           409 once picked up
GET  /v1/orders/{id}/events           SSE: status + rider location, resumable
POST {restaurant_webhook_url}         order.created, signed, retried

15.3 Common Follow-Up Questions#

16Chapter 16: Practice Problems#

Summary#

Further Reading#

API Guidelines#

• Docs

  Google API Improvement Proposals (AIP-121, 122, 132, 133, 134, 136, 151, 155, 158, 160, 180, 185, 193): https://google.aip.dev/general

• Docs

  Microsoft Azure REST API Guidelines: https://github.com/microsoft/api-guidelines/blob/vNext/azure/Guidelines.md

• Docs

  Stripe API reference (pagination, errors, idempotent requests) and API keys: https://docs.stripe.com/api · https://docs.stripe.com/keys

• Docs

  GitHub REST API docs (pagination, rate limits, versions): https://docs.github.com/en/rest

• Docs

  GitHub GraphQL API rate and query limits: https://docs.github.com/en/graphql/overview/rate-limits-and-query-limits-for-the-graphql-api

Engineering Posts#

• Blog

  Stripe — APIs as infrastructure: future-proofing Stripe with versioning (5 August 2017): https://stripe.com/blog/api-versioning

• Blog

  Stripe — Designing robust and predictable APIs with idempotency (22 February 2017): https://stripe.com/blog/idempotency

• Blog

  Slack — Evolving API Pagination at Slack (15 August 2017): https://slack.engineering/evolving-api-pagination-at-slack/

• Blog

  GitHub — The GitHub GraphQL API (14 September 2016): https://github.blog/news-insights/the-library/the-github-graphql-api/

• Blog

  Netflix — Practical API Design at Netflix, Part 1: Using Protobuf FieldMask (2021): https://netflixtechblog.com/practical-api-design-at-netflix-part-1-using-protobuf-fieldmask-35cfdc606518

• Read

  Markus Winand — No Offset (Use The Index, Luke): https://use-the-index-luke.com/no-offset

Standards and Protocol Docs#

• Docs

  RFC 9110 HTTP Semantics: https://www.rfc-editor.org/rfc/rfc9110

• Docs

  RFC 9457 Problem Details for HTTP APIs: https://www.rfc-editor.org/rfc/rfc9457

• Docs

  RFC 6585 (429 Too Many Requests): https://www.rfc-editor.org/rfc/rfc6585

• Docs

  IETF draft — RateLimit header fields for HTTP: https://datatracker.ietf.org/doc/draft-ietf-httpapi-ratelimit-headers/

• Docs

  RFC 6749 OAuth 2.0: https://www.rfc-editor.org/rfc/rfc6749

• Docs

  gRPC — Core concepts and status codes: https://grpc.io/docs/what-is-grpc/core-concepts/ · https://grpc.io/docs/guides/status-codes/

• Read

  GraphQL — Performance: https://graphql.org/learn/performance/

• Blog

  PostgreSQL — LIMIT and OFFSET: https://www.postgresql.org/docs/current/queries-limit.html

• Docs

  Shopify — REST Admin API (legacy notice): https://shopify.dev/docs/api/admin-rest
